Hihg Dc Current Gain--Min @Ic=1.5A VCE=5V
Collector Enitter Sustaining Voltage HEF=25
VCEO=100VDC--TIP35C TIP36C
25 AMPERE
40-100 VOLTS
125 WATTS TO-247(3P)
MAXIMUM
RATINGS
Characteristic
|
Symbol
|
TIP35C
|
TIP36C
|
Unit
|
Collector-Emitter Voltage
|
VCEO
|
100
|
100
|
V
|
Collector-Emitter Voltage
|
VCBO
|
100
|
100
|
V
|
Emitter-Base Voltage
|
VEBO
|
5.0
|
V
|
Collector Current-Continuous
-Peak
|
IC
|
25.0
40
|
A
|
Base Current
|
IB
|
5
|
A
|
Total Power Dissipation @TC=25℃
Derate above 25℃
|
PD
|
125
1.0
|
W
W/℃
|
Operating and Storage Junction
Temperature Range
|
TJ TSTG
|
-65 TO +150
|
℃
|
PIN 1 BASE
2 COLLECTOR
3
EMITTER
