Hihg Dc Current Gain--Min @Ic=6A VCE=1.5V
Collector Enitter Sustaining Voltage
VCEO=100VDC--TIP41C TIP42C
6 AMPERE
40-100 VOLTS
65 WATTS
MAXIMUM
RATINGS
Characteristic
|
Symbol
|
TIP41B
|
TIP41C
|
Unit
|
Collector-Emitter Voltage
|
VCEO
|
60
|
100
|
V
|
Collector-Emitter Voltage
|
VCBO
|
60
|
100
|
V
|
Emitter-Base Voltage
|
VEBO
|
5.0
|
V
|
Collector Current-Continuous
-Peak
|
IC
|
6.0
10.0
|
A
|
Base Current
|
IB
|
2.0
|
A
|
Total Power Dissipation @TC=25℃
Derate above 25℃
|
PD
|
65
0.52
|
W
W/℃
|
Operating and Storage Junction
Temperature Range
|
TJ TSTG
|
-65 TO +150
|
℃
|
PIN ?BASE
?COLLECTOR
?EMITTER
?COLLECTOR(CASE)
