HIGH VOLTAGE APPLICATION
EPITAXIAL PLANAR REANSISTOR
MAXIMUM
RATINGS
|
 Characteristic
 |
 Symbol
 |
 Rating
 |
 Unit
 |
|
 Collector-Emitter Voltage
 |
 VCEO
 |
 160
 |
 V
 |
|
 Collector-Base  Voltage
 |
 VCBO
 |
 160
 |
 V
 |
|
 Emitter-Base Voltage
 |
 VEBO
 |
 5
 |
 V
 |
|
 Collector Current-ontinuous

 |
 IC
 |
 1.5
 |
 A
 |
|
 Peak collector Current
 |
 Icp
 |

 |
 A
 |
|
 Collector power dissipation
 |
 PC
 |
 10
 |
 W
 |
|
 Operating and Storage Junction
 |
 TSTG
 |
 -55 TO +150
 |
 ℃
 |
