PNP SILICON POWER TRANSISTOR
MAXIMUM
RATINGS
Characteristic
|
Symbol
|
Rating
|
Unit
|
Collector-Emitter Voltage
|
VCEO
|
-40
|
V
|
Collector-Emitter Voltage
|
VCBO
|
-30
|
V
|
Emitter-Base Voltage
|
VEBO
|
-5
|
V
|
Collector Current-Continuous
|
IC
|
-3
|
A
|
Base Current
|
IB
|
|
A
|
Total Power Dissipation TA=25℃
Derate above 25℃ @TC=25℃
|
PC
|
1.0
|
W
W
|
Operating and Storage Junction Temperature
Range
|
TJ TSTG
|
-45 TO +150
|
℃
|
PIN
1 EMITTER
2 COLLRCTOR
3 BASE
