Matierial:
Pin(outer sleeve):
Brass,machined
Clip(cotact 4 finger):
Beryllium Copper,heat treated
Plating(outer sleeve):
Tin plated:
2mm/80u"Ni, 5mm/200μ"Sn
Plating(coctact):
2mm/80u"Ni, gold or Tin plated
Insulator(black):
Glass filled thermoplastic polyester UL94V-0
Electrical:
Current rating:
3Amps/contact max.
Contact resistance:
?4mΩ/contact
Insulation resistance:
?1000MΩ at V=100V
Operaing voltage:
60VAC/DC
Mechanical:
Average insertion force with steel pin of Φ0.43mm/0.017":
<250g
Average withdrawal force with steel pin of Φ0.43mm/0.017":
>50g min.
Mechanical life cycle:min.200
Operaing temperatures:
Gold Plsted:-55°C to+ 150°C
Tin plated:-40°C to+ 150°C
Soldering temperature:
+260°C,10s max.
